Data Sheet (Fields marked with * are required fields)

Name: *

Quote Reference#

	Quote Ref# is generated when you submit a Quote Request.
	The more information you give, the better sails we can make for you. For spaces unfilled, information will be taken as unknown and we will use our expertise for them.)

Click on the pictures below for a magnified copy. Please be patient for the slightly longer download time on a slow Internet link.





-->

MAIN, MIZZEN

1.

Main mast rig: masthead or fractional

2.

Maximum mast bend: Main Mizzen

3.

Roller reefing boom? Main: Yes No Mizzen: Yes No

4.

Battens?
Main: Short Full length None
Mizzen: Short Full length None

5.

Type of sail track (see Dwg. 1). Pls give (1), (2), (3) or (4). If (1) or (2), please specify if slides/slugs or boltrope required:

MAIN

Mast: Brand Model

Type X Y Z (slide rope )

Boom: Brand Model

Type X Y Z (slide rope )

Gaff: Type X Y Z (lacing )

MIZZEN / TRYSAIL / STAYSAIL

Mast: Brand Model

Type X Y Z (slide rope )

Boom: Brand Model

Type X Y Z (slide rope )

Gaff: Type X Y Z (lacing )

6.

Tack Cutback (see Dwg. 2)

Please illustrate by diagram or photos if your fittings are different from this drawing.

	MAIN	MIZZEN
A
E
C
H

Do you have Reef hooks? Yes No

If yes, please give

RA

Do you have Tack Jaw? Yes No

If yes, please give

G

Do you have Outhaul Car? Yes No

If yes, please give

B
D

Does the Outhaul Car have a Jaw? Yes No

If yes, please give

F

7.

Reef points. Please give distances above boom.

Main: 1st 2nd 3rd

Mizzen: 1st 2nd 3rd

8.

Insignia? No Yes Colour

Sail Number: No Yes Colour

Please provide sketch for insignia, if possible, in jpg/gif format via email or directly by fax.

HEADSAIL

9.

Luff attachment method (specify in or mm):

Jib Hank to fit forestay dia. ,

inner stay dia.

Lufftape to fit groove (see Dwg. 3)

Inside dia.: X Opening: Y

Foil/Furling system Brand Model

Stiff Wire Furling, Pin dia. ,

Jaw width

Set Flying

10.

Furling Headsails? Yes No

If yes, (see Dwg. 3)

Max Sail Hoist S =

Cut Back V =

Tack To Feeder W =

Colour of sunstrip required

Sunstrips are sewn on starboard side. Yes No

11.

Does staysail have a club boom? Yes No

If yes, foot is loose , laced , or with slides as stated in 5 above.

12.

Wire strap, if required for (which sail )

length at head length at tack

RADIAL HEAD DRIFTER, BLISTER (ASYMMETRICAL CRUISING SPINNAKER)

13.

Tack Attachment: to normal wire forestay or furled headsail on forestay

SPINNAKER

14.

We take the spinnaker required to be the only spinnaker on board for ALL PURPOSES. Otherwise, please specify if it is for heavy weather or light wind.

Additional Information:

* To make a copy of this form, please print using your browser's print function before pressing the Submit button.
